COLLECTIONS
SLOTTED

Sump covers with classic slotted designs in a variety of standard sizes and shapes for quick matches to your designs.

51110

SC300-300H25LD

Load class A15
Drain width 250 x 250mm (Pit Size)
Dimension 300W x 300L x 25mm(t)
51111

SC300-300H35HD

Load class B125
Drain width 230 x 230mm (Pit Size)
Dimension 300W x 300L x 35mm(t)
51112

SC300-600H25LD

Load class A15
Drain width 250 x 550mm (Pit Size)
Dimension 300W x 600L x 25mm(t)
51113

SC300-600H35HD

Load class B125
Drain width 240 x 540mm (Pit Size)
Dimension 300W x 600L x 35mm(t)
51120

SC400-400H35LD

Load class A15
Drain width 350 x 350mm (Pit Size)
Dimension 400W x 400L x 35mm(t)
51121

SC400-400H35HD

Load class B125
Drain width 340 x 340mm (Pit Size)
Dimension 400W x 400L x 35mm(t)
51122

SC400-500H35LD

Load class A15
Drain width 350 x 450mm (Pit Size)
Dimension 400W x 500L x 35mm(t)
51123

SC400-500H35HD

Load class B125
Drain width 340 x 440mm (Pit Size)
Dimension 400W x 500L x 35mm(t)
51124

SC420-625H35LD

Load class A15
Drain width 370 x 575mm (Pit Size)
Dimension 420W x 625L x 35mm(t)
51125

SC420-625H35HD

Load class B125
Drain width 360 x 565mm (Pit Size)
Dimension 420W x 625L x 35mm(t)
51126

SC435-873H35LD

Load class A15
Drain width 385 x 823mm (Pit Size)
Dimension 435W x 873L x 35mm(t)
51127

SC435-873H35HD

Load class B125
Drain width 375 x 813mm (Pit Size)
Dimension 435W x 873L x 35mm(t)
51128

SC500-500H35LD

Load class A15
Drain width 450 x 450mm (Pit Size)
Dimension 500W x 500L x 35mm(t)
51129

SC500-500H35HD

Load class B125
Drain width 440 x 440mm (Pit Size)
Dimension 500W x 500L x 35mm(t)
51130

SC550-550H35LD

Load class A15
Drain width 500 x 500mm (Pit Size)
Dimension 550W x 550L x 35mm(t)
51131

SC550-550H50HD

Load class B125
Drain width 490 x 490mm (Pit Size)
Dimension 550W x 550L x 50mm(t)
Jonite Reinforced Stone Basin Grates Slotted shop drawing
53110C

TRF300-300H25

Suitable for SC300-300H25LD
Jonite Reinforced Stone Basin Grates Slotted shop drawing
53111C

TRF300-300H35

Suitable for SC300-300H35HD
Jonite composite stone Basin Grates Slotted shop drawing
53112C

TRF300-600H25

Suitable for SC300-600H25LD
Jonite Reinforced Stone Basin Grates Slotted Long shop drawing
53113C

TRF300-600H35

Suitable for SC300-600H35HD
Jonite Reinforced Stone Basin Grates Slotted shop drawing
53114C

TRF400-400H35

Suitable for SC400-400H35LD / HD
Jonite Reinforced Stone Basin Grates Slotted shop drawing
53115C

TRF500-500H35

Suitable for SC500-500H35LD / HD
